I/O Memory Allocation Section 9-3
205
CS/CJ-series PLC CX-Simulator
Item
Settings Function Settings Function
Special I/O Unit Cyclic
Refreshing
Units 0 to 95
0: Enabled
1: Disabled
Default: 0
These settings determine
whether data will be exchanged
between the specified Unit and
the Special I/O Unit’s allocated
words (10 words/Unit) during
cyclic refreshing for Special I/O
Units.
Not used.
9-3-2 Auxiliary Area (Read-only Area)
A000 to A447: Read-only Area, A448 to A959: Read/Write Area
Address CS/CJ-series PLC CX-Simulator
Words Bits
Name
Function Settings Function Settings
A050 to
A089
Basic I/O
Unit Infor-
mation.
A bit will turn ON to indicate when
a fuse has blows. The bit num-
bers correspond to the fuse num-
ber on the Unit.
1: Fuse
blown
0: Normal
Not used.
A09914 IR/DR Op-
eration
between
Tasks
(CS1-H
CPU Units
only)
Turn ON this bit to share index
and data registers between all
tasks. Turn OFF this bit to use
separate index and data registers
in each task.
1: Shared
(default)
0: Inde-
pendent
Same as
CS/CJ-series
PLC.
A099
A09915 Timer/
Counter
Present
Value Re-
fresh
Method
Flag
(CS1-H
CPU Units
only)
Indicates if the CPU Unit is using
BCD or binary (hexadecimal) for
timer/counter operation.
1: Binary
0: BCD
Same as
CS/CJ-series
PLC.
