Debug Console Window Section 3-9
97
Contents of Menu
Name Function
Tasks Display the task menu.
Help Display the information on Help and the version.
Menu List of [Step Run] Window
Main Menu Submenu Shortcut Function
Run Mode Turn the selected cyclic task into the execution
mode.
Wait Mode Turn the selected cyclic task into the standby
mode.
Cyclic tasks
Block Run Execute the selected cyclic task in block. Used in
Program mode.
Start Start the selected task as an extra cyclic task. Extra cyclic
tasks
Stop Stops the selected task.
Activate Interrupt Task In Program mode, execute the selected interrupt
task in block. In Monitor/Run mode, an interrupt
occurs at the moment and the process moves to
the specified interrupt task.
Copy task data Copy the list of Task Control being displayed to
the clipboard.
Tasks
Exit Close the Task Control window.
Help Contents Display the Help Contents
Help Index Display the Help Index.
Help
About Display the version information.
Content of Pop-up Menu
Clicking the task line and right-clicking will display the pop-up menu.
Name Function
Execution Mode Turn the selected cyclic task to Execution mode.
Standby Mode Turn the selected cyclic task to Standby mode.
Cyclic Task
Execution in Block Execute the selected cyclic task in block. Available only
in Program mode.
Interrupt Task Startup In Program mode, execute the selected interrupt task
in block. In Monitor/Run mode, an interrupt occurs at
the moment and the process moves to the specified
interrupt task.
Copy Copy the list of Task Control being displayed to the
clipboard.
Close Close the Task Control window.
Note
1. Block execution of task sets a start point at the top of the task and a break
point at the bottom (END line), and operates in the same way as Step Run.
2. Refer to 4-4 Task Debugging for the details of Task Control.
3-9-9 I/O Break Condition Settings Window
I/O Break Condition Setting sets the values of I/O memory with the logical
equation and registers the I/O Break Conditional Equation for breaking at the
step where the set equation holds.
