Debugging Operation Section 4-2
106
4-2-5 Pause ( )
Pause pauses executing the ladder diagram.
The situation is also the same when the execution of the ladder program is
stopping in Scan Run, Step Run, a break point, or an I/O break condition.
While pausing, the peripheral servicing is performed.
4-2-6 Other Operation
Scan Replay ( )
The Scan Replay returns the execution status to the first of the scan when
pausing.
The Scan Replay returns all of the status including values changed by the
program execution to that of the scan start.
As long as it is within a scan, monitoring can be done with conditions changed
any times.
Reset ( )
The Reset simulates the process in the Ladder Engine when from power in-
terruption to power on. The power interruption task is started at power inter-
ruption to allow debugging the power interruption process (only when regis-
tered).
Returning from the Reset turns the mode to Program.
