5-5 Examples of Serial Communications Debugging
5-5-1 Procedure for Debugging Serial Communications Instructions
1,2,3…
1. Set the communications settings of serial communications to "-" to debug
the portions unrelated to serial communications.
Display the [Serial Comm. Setting] window by [Status] | [Settings] |
[Serial Comm. Setting].
Set the communications settings for all the Serial Communications
Units to "-."
2. Set the communications settings of serial communications to "Messages"
to display send messages through actual serial communications. Check
the contents of the send messages.
Display the [Serial Comm. Setting] window by [Status] | [Settings] |
[Serial Comm. Setting].
Set the communications settings for the Serial Communications Units
to be debugged to "Messages."
3. Set the communications settings of serial communications to "File" to
debug the serial communications portion by file I/O instead of actual serial
communications.
Display the [Serial Comm. Setting] window by [Status] | [Settings] |
[Serial Comm. Setting].
Set the communications settings for the Serial Communications Units
to be debugged to "File."
4. Set the communications settings of serial communications to "Actual
communications." Connect the actual communications target to the
computer’s COM port, and after confirming Setup for serial communica-
tions with I/O Memory Allocation, debug operations with actual serial
communications.
Display the [Serial Comm. Setting] window by [Status] | [Settings] |
[Serial Comm. Setting].
Set the communications settings for the Serial Communications Units
to be debugged to "Actual communications."
Confirm the Setup of the Unit for serial communications with I/O
Memory Allocation,
Caution
Enabling serial communications function of the CX-Simulator may affect the
operation of devices connected to the computer. When external devices are
not being used, do not enable the serial communications function. Unex-
pected operation of the external devices may cause an accident.
