Connection with Application Programs Section 7-2
155
Note
For instructions on setting the routing tables (including the relay network
table), refer to Section 3 of the CX-Integrator Operation Manual (W464).
7. Set the relay network table for the Ladder Engine.
8. Set the Run mode of the Ladder Engine to [Continuous Run] in the [Debug
Console] window.
9. Execute the application program to check its operation.
Note
The relay network table will be deleted when [Disconnect]. Set the relay net-
work table using the CX-Integrator again after [Connect] when needed.
