Running by Virtual External Inputs Section 8-4
177
Basic Operation
Command log
(Ladder Engine)
Commercial
spreadsheet, etc.
CX-Programmer
or
Data Trace Re-
cording Tool
Command log
file (.flg)
Data Trace file
(.cdt)
Data Replay
file (.csv)
Data Replay Tool
Ladder Engine
Data Replay
file (.csv)
FINS command
Replay
file
Output file
Read data from input
file.
Read output data
from Ladder Engine.
Wait at fixed interval.
(
e
q
uivalent to one scan
)
One Scan Run
Set data to Ladder
Engine.
Asynchronous Synchronous
Write output data to
output file.
