Running by Virtual External Inputs Section 8-4
183
2. Select [Debugger program area (UM2)] in [UM Access Enable] followed
by clicking the [OK] button.
3. After confirming that the CX-Simulator is connected in the [Work
CX-Simulator] window, download the ladder program from the
CX-Programmer.
4. After the download is completed, select [UM Settings] in [System Status] |
[Settings] again and select [Application program area (UM1)] in [UM Ac-
cess Enable]. Also, check both boxes for [Application program area
(UM1)] and [Debugger program area (UM2)] in [UM Execution Enable],
followed by clicking the [OK] button.
5. Select [Save all] in the [CX-Simulator Debug Console] | [File] menu to
save the status before starting virtual external inputs.
6. Clicking the [Continuous Run] button from [CX-Simulator Debug Console]
or turning the mode of the Ladder Engine to Monitor from the
CX-Programmer will start running using virtual external inputs.
Note
The CX-Simulator can not debug a ladder program in the program area for
debugging. Before downloading the ladder program to the program area for
debugging, check it in the area for applications in advance.
