xxvii
Name Cat. No. Use Contents
SYSMAC CS/CJ/CP/NSJ Series
CS1G/H-CPU@@-EV1,
CS1G/H-CPU@@H,
CS1D-CPU@@H, CS1D-CPU@@S,
CJ2H-CPU6@-EIP, CJ2H-CPU6@,
CJ1H-CPU@@H-R, CJ1G-CPU@@,
CJ1M-CPU@@, CJ1G-CPU@@P,
CJ1G/H-CPU@@H,
CS1W-SCU@@-V1,
CS1W-SCB@@-V1,
CJ1W-SCU@@-V1,
CP1H-X@@@@-@,
CP1H-XA@@@@-@,
CP1H-Y@@@@-@,
NSJ@-@@@@ (B)-G5D,
NSJ@-@@@@(B)-M3D
Communications Commands Refer-
ence Manual
W342 To learn about communi-
cations commands ad-
dressed to
CS/CJ/CP-series CPU
Units and NSJ-series
Controllers.
Describes the following information.
• C-mode commands
• FINS commands
Note: Refer to this manual when sending C-mode or FINS
commands to the CPU Unit.
This manual describes commands addressed to the
CPU Unit without reference to the communications path.
(Commands can be sent via the serial ports on the CPU
Unit, ports on a Serial Communications Board or Unit, or
ports on Communications Units.)
NSJ5-TQ@@(B)-G5D
NSJ5-SQ@@(B)-G5D
NSJ8-TV@@(B)-G5D
NSJ10-TV@@(B)-G5D
NS12-TS@@(B)-G5D
NSJ Series NSJ Controllers
Operation Manual
W452 To learn the basic specifi-
cations of the NSJ-series
NSJ Controllers, including
a basic outline, settings,
installation, and mainte-
nance.
Describes the following information about the NSJ-series NSJ
Controllers:
Overview and features
Designing the system configuration
Installation and wiring
I/O memory allocations
Troubleshooting and maintenance
Use this manual in combination with the following manuals:
SYSMAC CS Series Operation Manual (W339), SYSMAC CJ
Series Operation Manual (W393), SYSMAC CS/CJ Series
Programming Manual (W394), and NS-V1/-V2 Series Setup
Manual (V083)
CP1H-X@@@@-@,
CP1H-XA@@@@-@,
CP1H-Y@@@@-@,
SYSMAC CP Series
CP1H CPU Unit
Operation Manual
W450 To learn the basic specifi-
cations of the CP-series
CP1H CPU Units, includ-
ing a basic outline, set-
tings, installation, and
maintenance.
Provides the following information on the CP Series CP1H
CPU Unit:
• Overview/Features
• System configuration
• Mounting and wiring
• I/O memory allocation
• Troubleshooting
Use this manual together with the CP1H Programmable Con-
trollers Programming Manual (W451).
CP1L-M@@@@-@,
CP1L-L@@@@-@,
CP Series CP1L Operation Manual
W462 To learn the basic specifi-
cations of the CP-series
CP1L CPU Units, including
a basic outline, settings,
installation, and mainte-
nance.
Provides the following information on the CP Series CP1L
CPU Unit:
• Overview/Features
• System configuration
• Mounting and wiring
• I/O memory allocation
• Troubleshooting
Use this manual together with the CP1H Programmable Con-
trollers Programming Manual (W451).
CP1H-X@@@@-@,
CP1H-XA@@@@-@,
CP1H-Y@@@@-@,
CP1L-M@@@@-@,
CP1L-L@@@@-@
SYSMAC CP Series
CP1H/CP1L CPU Unit Programming
Manual
W451
To learn about program-
ming CP-series
CP1H/CP1L CPU Units.
Provides the following information on the CP Series
CP1H/CP1L CPU Unit:
• Programming instructions
• Programming methods
• Tasks
WARNING
Failure to read and understand the information provided in this manual may result in
personal injury or death, damage to the product, or product failure. Please read each
section in its entirety and be sure you understand the information provided in the section
and related sections before attempting any of the procedures or operations given.
