Nomenclature and Basic Operation Section 1-3
Operation Button Names and Operations
Button Function
Menus Writing ladder program Setting parameters Button switch
(See page 99.)
DEL
--- Deletes inputs, outputs,
connection lines, and blank
lines.
--- B6 ON
ALT
--- Switches between normally
open and normally closed
conditions.
Changes to connection line
write mode.
Inserts a line.
--- B7 ON
Up
Moves the
cursor up and
down.
Moves the cursor up and
down.
Selects bit types and
functions.
Moves the cursor up
and down.
Changes numerals
and parameters.
B5 ON
Down
B2 ON
Left
--- Moves the cursor right and
left.
Moves the cursor
right and left.
B3 ON
Right
B4 ON
ESC
Returns to the
previous
screen.
Cancels the setting and
returns to the previous
operation.
Cancels the setting
and returns to the
previous operation.
B0 ON
OK
Selects the
menu item at
the cursor
position.
Confirms the setting. Confirms the setting. B1 ON
Z211-E1-03.book Page 17 Friday, November 21, 2008 10:38 AM

Omron ZEN Specifications

General

Display	LCD
Mounting Type	DIN Rail
Operating Temperature	-10 to 55°C
Power Supply Voltage	100-240V AC
Output Type	Relay, Transistor
Number of Outputs	4-8
Programming Language	Ladder Logic
