Installing a ZS5-2 Controller
This section contains installation procedures for the ZS5-2 controller.
Before beginning installation, see “Installation Prerequisites and Hardware
Overviews” on page 15.
Use the following procedures to install a ZS5-2 controller:
■
“Installing the Mounting Brackets and Slide Rail Assemblies for a ZS5-2” on page 157
■
“Installing a ZS5-2 onto the Rack Slide Rails” on page 163
■
“Installing a ZS5-2 Cable Management Arm” on page 164
■
“Verifying Operation of ZS5-2 Slide-Rails and CMA” on page 174
Installing the Mounting Brackets and Slide Rail
Assemblies for a ZS5-2
Use the following procedure to install the mounting brackets and slide rail assemblies for a
ZS5-2 controller.
1.
Unpack the slide rails and locate the slide rail lock at the front of the assembly.
2.
Squeeze and hold the tabs at top and bottom of the lock (1) while you pull the
mounting bracket out to the stop.
Installing a ZS5-2 Controller 157
