Overview of ZS9-2 Controller
ZS9-2 Electrical Specifications
The ZS9-2 controller has two hot-swappable rear accessible power supplies with N+N
redundancy. To understand the overall power consumption, see Oracle's online power calculator
at http://www.oracle.com/goto/powercalculators.
Parameter AC Power Supplies
Nominal input frequencies 50/60 Hz
Operating input voltage range 100-240 VAC
Rated input current 10 A @ 100 to 127 VAC, and 7 A @ 200 to 240 VAC
Maximum power consumption of controller
Refer to the Power Calculator (https://www.oracle.
com/goto/powercalculators) and see Oracle ZFS
Storage ZS9-2 for Watt calculations
Maximum heat output of controller
Refer to the Power Calculator (https://www.oracle.
com/goto/powercalculators) and see Oracle ZFS
Storage ZS9-2 for BTU/hr calculations
ZS9-2 Acoustic Noise Emissions
The workplace-dependent noise level of this product is 9.5 Bels A-weighted Operating, and 8.0
Bels A-weighted Idling (measured Sound Power).
ZS9-2 Configuration Options
The ZS9-2 high-end model incorporates one or two controllers and one to forty-eight disk
shelves. Each controller has 10 PCle Gen3 slots in the rear, and 12 3.5" disk slots in the front,
two of which are occupied by system disks. The remaining ten front disk slots have permanent
filler panels. The following table describes the configuration options.
CPU Memory System Disks PCIe Slots HBA
2x32-core, 2.6 GHz 2.0 TB 2x3.5'' NVMe Five dedicated; five
available
4-port (4x4) SAS-3
12 Gb/s external
The ZS9-2 mid-range model incorporates one or two controllers and one to twenty-four disk
shelves. Each controller has 10 PCle Gen3 slots in the rear, and 12 3.5" disk slots in the front,
Installation Prerequisites and Hardware Overviews 45
