Overview of ZS5-2 Controller
Parameter AC Power Supplies
Rated input current 10 A @ 100 VAC
9 A @110-127 VAC
5.5 A @ 200-240 VAC
ZS5-2 Acoustic Noise Emissions
In compliance with the requirements defined in ISO 9296, the workplace-dependent noise level
of this product is less than 75 dBA.
ZS5-2 Configuration Options
The ZS5-2 incorporates one or two controllers and one to sixteen disk shelves. Each controller
has six PCIe Gen3 slots. Each controller includes eight 2.5'' disk slots that accommodate two
system disks. Read cache devices are installed in disk shelves; therefore, the remaining six disk
slots have permanent filler panels. The following table describes the configuration options.
CPU Memory System Disks PCIe Slots HBA
2x18-core, 2.3 GHz 384 GB
768 GB
2x2.5'' SAS-3 Two dedicated; four
available
4-port (4x4) SAS-3
12 Gb/s external
4-port (4x4) SAS-2 6
Gb/s external
Refer to https://oracle.com/zfsstorage for the most recent component specification.
ZS5-2 Front Panel Components
The ZS5-2 controller drive slots and front panel components are shown in the following figure.
58 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021
