Oracle ZFS User Manual

Overview of ZS3-2 Controller
■
Max power consumption: 890 W max
■
Max heat output: 3026 BTU/hr
■
Volt-Ampere rating: 908 VA @ 240 VAC, 0.98P.F.
ZS3-2 Acoustic Noise Emissions
In compliance with the requirements defined in ISO 7779, the workplace-dependent noise level
of this product is less than 70 db (A).
ZS3-2 Configuration Options
The ZS3-2 controller is an enterprise-class, rackmount x86 system powered by the Intel Xeon
processor. It provides high performance and room for growth with expandable PCIe slots and
16 DIMM slots in a compact 2U footprint. The following table describes the configuration
options.
CPU Memory Readzilla Boot Drive PCIe Slots HBA
2x8-core, 2.1
GHz
256GB
16x16GB
512GB
16x32GB
1-4 SAS SSDs Two 2.5-inch
SAS HDDs
Two dedicated;
four available
4-port (4x4)
SAS-3 12Gb/s
external
4-port (4x4)
SAS-2 6Gb/s
external
Refer to https://oracle.com/zfsstorage for the most recent component specification.
ZS3-2 Front Panel Components
The ZS3-2 controller drive slots and front panel components are shown in the following figure.
Installation Prerequisites and Hardware Overviews 71

Oracle ZFS Specifications

General

Category	Storage
Operating System	Oracle Solaris
Protocol Support	NFS, SMB, iSCSI, FC
Data Protection	Snapshots, Clones, Replication
Encryption	AES-256 encryption for data at rest
Integration	Oracle Database
RAID Levels	RAID-Z2, RAID-Z3
Data Deduplication	Yes
Data Integrity	Checksums
High Availability	Redundant hardware
Maximum Capacity	Petabytes
Management	Command-line interface (CLI)
