Overview of ZS7-2 Controller
16 Cluster interface card (slot 6) 17 First PCIe option (slot 7) 18 Slot 8:
■ High-end model: External SAS-3
HBA
■ Mid-range model: Filler panel;
slot not available
19 External SAS-3 HBA (slot 9) 20 Fourth PCIe option (slot 10)
For information about how to connect cables to form a cluster, see “Connecting Cluster
Cables” on page 220.
Overview of ZS7-2 Controller
This section provides an overview of the Oracle ZFS Storage ZS7-2 controller. For installation
instructions, refer to “Installing a ZS7-2 Controller” on page 131. For service instructions,
refer to “Servicing the ZS7-2 Controller” in Oracle ZFS Storage Appliance Customer Service
Manual.
Refer to https://oracle.com/zfsstorage for the most recent component specification.
ZS7-2 Physical Specifications
The ZS7-2 controller chassis dimensions are as follows:
Dimension Measurement Dimension Measurement
Height 3.42 in./8.69 cm Depth 29.9 in./75.9 cm
Width 17.5 in./44.5 cm Weight (Maximum) 63 lb./28.6 kg
ZS7-2 Electrical Specifications
The ZS7-2 controller has two hot-swappable rear accessible power supplies with N+N
redundancy. To understand the overall power consumption, see Oracle's online power calculator
at http://www.oracle.com/goto/powercalculators.
Parameter AC Power Supplies
Nominal input frequencies 50/60 Hz
Installation Prerequisites and Hardware Overviews 49
