Oracle ZFS User Manual

Overview of 7320 Controller
7320 Front Panel Components
The following figure and legend identify the front panel LEDs.
FIGURE 43
7320 Controller Front Panel
Figure Legend
1 Locate Button/LED 2 Service Required LED (amber) 3 Power/OK LED (green)
4 Power Button 5 Rear Power Supply 6 System Overtemperature LED
7 Top Fan
The following figure and legend identify the 7320 front panel drive locations. Two mirrored
hard disk drives (HDDs) that store the operating system reside in slots 0 and 1. Up to four solid
state drives (ReadZilla SSDs), which store the read cache, fill slots 2 through 5, in order. Slots 6
and 7 are empty and must contain drive fillers.
FIGURE 44
7320 Front Panel Drive Locations
82 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021

Oracle ZFS Specifications

General

Category	Storage
Operating System	Oracle Solaris
Protocol Support	NFS, SMB, iSCSI, FC
Data Protection	Snapshots, Clones, Replication
Encryption	AES-256 encryption for data at rest
Integration	Oracle Database
RAID Levels	RAID-Z2, RAID-Z3
Data Deduplication	Yes
Data Integrity	Checksums
High Availability	Redundant hardware
Maximum Capacity	Petabytes
Management	Command-line interface (CLI)
