Overview of ZS9-2 Controller
This section provides an overview of the Oracle ZFS Storage ZS9-2 controller. For installation
instructions, refer to “Installing a ZS9-2 Controller” on page 115. For service instructions,
refer to “Servicing the ZS9-2 Controller” in Oracle ZFS Storage Appliance Customer Service
Manual.
Refer to https://oracle.com/zfsstorage for the most recent component specification.
ZS9-2 Physical Specifications
The ZS9-2 controller chassis dimensions are as follows:
Dimension Measurement Dimension Measurement
Height 3.42 in./86.9 mm Depth 30.04 in./772 mm
Width 18.97 in./482 mm Weight (Maximum) 48 lb./21.41 kg
