Overview of ZS7-2 Controller
Parameter AC Power Supplies
Operating input voltage range 100-240 VAC
Rated input current 10 A @ 100 to 127 VAC and 7 A @ 200 to 240 VAC
Maximum power consumption of controller
Refer to the Power Calculator (https://www.oracle.
com/goto/powercalculators) and see Oracle Server
X7-2L for Watt calculations
Maximum heat output of controller
Refer to the Power Calculator (https://www.oracle.
com/goto/powercalculators) and see Oracle Server
X7-2L for BTU/hr calculations
ZS7-2 Acoustic Noise Emissions
The workplace-dependent noise level of this product is 8.1 Bels A-weighted Operating, and 5.8
Bels A-weighted Idling (measured Sound Power).
ZS7-2 Configuration Options
The ZS7-2 high-end model incorporates one or two controllers and one to forty-eight disk
shelves. Each controller has 11 PCle Gen3 slots in the rear, and 12 3.5" disk slots in the front,
two of which are occupied by system disks. Read cache devices are installed in disk shelves;
therefore, the remaining ten front disk slots have permanent filler panels. The following table
describes the configuration options.
CPU Memory System Disks PCIe Slots HBA
2x24-core, 2.1 GHz 1.5 TB 2x3.5'' SAS-3 Six dedicated; five
available
4-port (4x4) SAS-3
12 Gb/s external
The ZS7-2 mid-range model incorporates one or two controllers and one to sixteen disk shelves.
Each controller has 11 PCle Gen3 slots in the rear, and 12 3.5" disk slots in the front, two of
which are occupied by system disks. Read cache devices are installed in disk shelves; therefore,
the remaining ten front disk slots have permanent filler panels. The following table describes
the configuration options.
CPU Memory System Disks PCIe Slots HBA
2x18-core, 2.3 GHz 512 GB or 1024 GB 2x3.5'' SAS-3 Four dedicated;
five available;
two unavailable
4-port (4x4) SAS-3
12 Gb/s external
50 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021
