Overview of ZS5-4 Controller
Dimension Measurement Dimension Measurement
Width 17.2 in./436.5 mm Weight (Maximum) 88 lb./40 kg
ZS5-4 Electrical Specifications
The ZS5-4 controller has two hot-swappable rear accessible power supplies with N+N
redundancy. To understand the overall power consumption, see Oracle's online power calculator
at http://www.oracle.com/goto/powercalculators.
Parameter AC Power Supplies
Nominal input frequencies 50/60 Hz
Operating input voltage range 200-240 VAC
Rated input current 10 A @ 200 to 240 VAC
Maximum power consumption 200W
Maximum heat output 6824 BTU/hr
ZS5-4 Acoustic Noise Emissions
In compliance with the requirements defined in ISO 9296, the workplace-dependent noise level
of this product is less than 75 dBA (bystander position, max. ambient).
ZS5-4 Configuration Options
The ZS5-4 incorporates one or two controllers and one to forty-eight disk shelves. Each
controller has eleven PCle Gen3 slots. Each controller includes six 2.5'' disk slots that
accommodate two system disks. Read cache devices are installed in disk shelves; therefore,
the remaining four disk slots have permanent filler panels. The following table describes the
configuration options.
CPU Memory System Disks PCIe Slots HBA
4x18-core, 2.6 GHz 1536 GB 2x2.5'' SAS-3 Four dedicated;
seven available
4-port (4x4) SAS-3
12 Gb/s external
4-port (4x4) SAS-2 6
Gb/s external
54 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021
