Oracle ZFS - ZS7-2 Front Panel Components

Overview of ZS7-2 Controller
CPU Memory System Disks PCIe Slots HBA
(permanent filler
panels)
The most recent component specification is located at https://www.oracle.com/storage/
nas/index.html.
ZS7-2 Front Panel Components
The ZS7-2 controller drive slots and front panel components are shown in the following figure.
FIGURE 24
ZS7-2 Front Panel
1 RFID tag 2 System status LED: Locator
(white)
3 System status LED: Service Action
Required (amber)
Installation Prerequisites and Hardware Overviews 51
