Oracle ZFS User Manual

Installing a ZS4-4 or ZS3-4 Controller
This section contains installation procedures for the ZS4-4 or ZS3-4 controller.
Before beginning installation, see “Installation Prerequisites and Hardware
Overviews” on page 15.
Use the following procedures to install a ZS4-4 or ZS3-4 controller:
■
“Installing the Slide Rails onto a ZS4-4 or ZS3-4” on page 175
■
“Installing the Slide Rails into the Rack for a ZS4-4 or ZS3-4” on page 176
■
“Installing a ZS4-4 or ZS3-4 onto the Rack Slide Rails” on page 178
■
“Installing a ZS4-4 or ZS3-4 Cable Management Arm” on page 181
Installing the Slide Rails onto a ZS4-4 or ZS3-4
Use the following procedure to install the slide rails onto a ZS4-4 or ZS3-4 controller.
Note - The slide rails can be used with either 9.5-mm square or M6 round mounting hole racks.
1.
Position a mounting bracket against the chassis so that the slide-rail lock is at
the front of the chassis, and the five keyhole openings on the mounting bracket
are aligned with the five locating pins on the side of the chassis.
Installing a ZS4-4 or ZS3-4 Controller 175

Oracle ZFS Specifications

General

Category	Storage
Operating System	Oracle Solaris
Protocol Support	NFS, SMB, iSCSI, FC
Data Protection	Snapshots, Clones, Replication
Encryption	AES-256 encryption for data at rest
Integration	Oracle Database
RAID Levels	RAID-Z2, RAID-Z3
Data Deduplication	Yes
Data Integrity	Checksums
High Availability	Redundant hardware
Maximum Capacity	Petabytes
Management	Command-line interface (CLI)
