Installing a ZS3-2 Controller
This section contains installation procedures for the ZS3-2 controller.
Before beginning installation, see “Installation Prerequisites and Hardware
Overviews” on page 15.
Use the following procedures to install a ZS3-2 controller:
■
“Installing the Mounting Brackets and Slide Rail Assemblies for a ZS3-2” on page 185
■
“Installing a ZS3-2 onto the Rack Slide Rails” on page 191
■
“Installing a ZS3-2 Cable Management Arm” on page 192
■
“Verifying Operation of ZS3-2 Slide-Rails and CMA” on page 201
Installing the Mounting Brackets and Slide Rail
Assemblies for a ZS3-2
Use the following procedure to install the mounting brackets and slide rail assemblies for a
ZS3-2 controller.
1.
Unpack the slide rails and locate the slide rail lock at the front of the assembly.
2.
Squeeze and hold the tabs at top and bottom of the lock (1) while you pull the
mounting bracket out to the stop.
Installing a ZS3-2 Controller 185
