Overview of ZS3-2 Controller
Overview of ZS3-2 Controller
This section provides an overview of the Oracle ZFS Storage ZS3-2 controller. For installation
instructions, refer to “Installing a ZS3-2 Controller” on page 185. For service instructions,
refer to “Servicing the ZS3-2 Controller” in Oracle ZFS Storage Appliance Customer Service
Manual.
ZS3-2 Physical Specifications
The ZS3-2 controller 2U chassis dimensions are as follows:
Dimension Measurement Dimension Measurement
Height 3.44 in./87.4 mm Depth 20.25 in./514 mm
Width 17.52 in./445 mm Weight 41.23 lb/18.70 kg
ZS3-2 Electrical Specifications
The ZS3-2 controller electrical specifications are listed below. The power dissipation numbers
listed are the maximum rated power numbers for the power supply. The numbers are not a
rating of the actual power consumption of the appliance.
Connectors
■
Two C13 connectors, which work on 110-220v outlets
Input
■
Nominal frequencies: 50/60Hz (47 to 63 Hz range)
■
Nominal voltage range: 100 to 120/200 to 240 VAC
■
Maximum current AC RMS: 6.8 A @ 100-120 V / 3.4 A @ 200-240 V
■
AC operating range: 90-264 VAC
Output
■
3.3 VDC STBY: 3.0A
■
+12 VDC: 86.7A
Power Dissipation
70 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021
