Overview of ZS3-2 Controller
Optional Cable Management Arm
The following figure identifies the components of the second-generation cable management arm
(CMA). See the CMA installation instructions.
FIGURE 39
Cable Management Arm Components
Figure Legend
1 Connector A 2 Front slide bar 3 Velcro straps (6)
Installation Prerequisites and Hardware Overviews 75
