Overview of ZS5-2 Controller
FIGURE 28
ZS5-2 Front Panel
1 LEDs: Locator, Service, Power 2 System disk 1 3 Permanent HDD filler panels
4 Two USB 2.0 ports 5 RFID tag 6 System disk 0
7 Alarm indicators (not used)
ZS5-2 Rear Panel Components
The ZS5-2 controller PCIe slots and rear panel components are shown in the following figure.
Installation Prerequisites and Hardware Overviews 59
