Overview of ZS5-2 Controller
Cluster Interface Card Compatibility - The ZS5-4 controller contains a Version 3 cluster
interface card, which is incompatible with Version 2.
For information about how to connect cables to form a cluster, see “Connecting Cluster
Cables” on page 220.
Overview of ZS5-2 Controller
This section provides an overview of the Oracle ZFS Storage ZS5-2 controller. For installation
instructions, refer to “Installing a ZS5-2 Controller” on page 157. For service instructions,
refer to “Servicing the ZS5-2 Controller” in Oracle ZFS Storage Appliance Customer Service
Manual.
Refer to https://oracle.com/zfsstorage for the most recent component specification.
ZS5-2 Physical Specifications
The ZS5-2 controller chassis dimensions are as follows:
Dimension Measurement Dimension Measurement
Height 3.43 in./87.1 mm Depth 25.2 in./640.0 mm
Width 17.52 in./445 mm Weight 38.5 lb./17.5 kg
ZS5-2 Electrical Specifications
The ZS5-2 controller has two N+1 AC redundant hot-swappable AC power supplies, rated 91%
efficiency. To understand the overall power consumption, see Oracle's online power calculator
at http://www.oracle.com/goto/powercalculators.
Parameter AC Power Supplies
Nominal input frequencies 50/60 Hz
Operating input voltage range 100 VAC (Japan only)
110-127 VAC (90-132 range)
200-240 VAC (180-264 range)
Installation Prerequisites and Hardware Overviews 57
