Oracle ZFS User Manual

Overview of 7320 Controller
7320 Electrical Specifications
The following list shows the electrical specifications for the 7320 controller.
Note - The power dissipation numbers listed are the maximum rated power numbers for the
power supply. The numbers are not a rating of the actual power consumption of the appliance.
Connectors
■
Two C13 connectors, which work on 110-220v outlets
Input
■
Nominal frequencies: 50/60Hz
■
Nominal voltage range: 100-120/200-240 VAC
■
Maximum current AC RMS: 9.0 amps Max
■
AC operating range: 90-264 VAC
Output
■
3.3 VDC STBY: 3.6A
■
+12 VDC: 62.3A
Power dissipation
■
Max power consumption: 873 W
■
Max heat output: 2977 BTU/hr
■
Volt-Ampere rating: 891 VA @ 240 VAC, 0.98P.F.
7320 Base Configurations
The 7320 controller base configuration options are:
■
Single or cluster
■
24GB or 96GB RAM
■
2x2.4GHz Quad-Core processors
■
One external SAS HBA
■
Four 10/100/1000 Ethernet ports
Installation Prerequisites and Hardware Overviews 81

Oracle ZFS Specifications

General

Category	Storage
Operating System	Oracle Solaris
Protocol Support	NFS, SMB, iSCSI, FC
Data Protection	Snapshots, Clones, Replication
Encryption	AES-256 encryption for data at rest
Integration	Oracle Database
RAID Levels	RAID-Z2, RAID-Z3
Data Deduplication	Yes
Data Integrity	Checksums
High Availability	Redundant hardware
Maximum Capacity	Petabytes
Management	Command-line interface (CLI)
