Overview of ZS3-4 Controller
FIGURE 35
System Boot Drive LEDs
Figure Legend
1 Ready to remove (blue) 2 Service action required (amber) 3 OK/Activity (green)
ZS3-4 Rear Panel Components
The following graphic shows the rear panel of the ZS3-4 controller. Base configuration HBAs
are not depicted in this illustration.
For information about PCIe cards, see “ZS3-4 PCIe I/O Cards” in Oracle ZFS Storage
Appliance Customer Service Manual.
FIGURE 36
ZS3-4 Rear Panel Components
68 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021
