Prerequisites for Installation
Note - Position the rack where the shelf is to be installed adjacent to the rack where the
controller is installed, if separate. Stabilize the cabinet and lock the casters. To facilitate access,
remove doors from cabinets.
Oracle Rack Cabinet 1242
Sun Rack II 1042/1242 cabinet
Any 19-inch wide, 4-post, EIA-compatible rack or cabinet with a front-to-back depth
between vertical cabinet rails of 61 cm to 91 cm (24 in. to 36 in.). The cabinet can have
threaded or unthreaded cabinet rails. Threaded cabinets must be M6 or 10-32 cabinets.
Cabinets must be able to support the weight of all equipment contained within them.
Use one of the following racks for a Sun Disk Shelf:
Note - Position the rack where the shelf is to be installed adjacent to the rack where the
controller is installed, if separate. Stabilize the cabinet and lock the casters.
Sun Rack 900/1000 cabinet
Sun Fire cabinet
Sun StorEdge Expansion cabinet
Sun Rack II 1042/1242 cabinet
Any 19-inch wide, 4-post, EIA-compatible rack or cabinet with a front-to-back depth
between vertical cabinet rails of 61 cm to 91 cm (24 in. to 36 in.). The cabinet can have
threaded or unthreaded cabinet rails.
To install a disk shelf, you need the following tools:
A Phillips-head No. 2 screwdriver that is a minimum of 4 inches long.
A T20 Torx driver, if using a threaded cabinet (DE2-24P).
A mechanical lift is highly recommended because the chassis can be too heavy to lift
otherwise. At least three people are required: two to install the shelf and one spotter to
engage the rails.
Note - For DEx-24 disk shelves, if a mechanical lift is not available, you can remove the
power supply with fan modules to reduce the weight. For instructions, refer to “Servicing
the Disk Shelves” in Oracle ZFS Storage Appliance Customer Service Manual.
A flashlight for the spotter to ensure the shelf is engaged in the rails.
To install a controller, you need the following tools:
No. 2 Phillips screwdriver
Installation Prerequisites and Hardware Overviews 17
