Overview of Disk Shelves
FIGURE 15
DE2 I/O Module Indicators
Figure Legend
1 Fault/Locate indicator 2 Power/OK indicator 3 SAS-2 Port 0
4 SAS-2 Port 1 5 SAS-2 Port 2 6 Host port activity indicators
7 For Oracle service only 8 For Oracle service only
The DE2-24C and DE2-24P disk shelves use the same I/O Module.
FIGURE 16
DE2 Power Supply Indicators
38 Oracle ZFS Storage Appliance Installation Guide, Release OS8.8.x • August 2021
