V–39
8) Model type 1 setting (Level 2)
Rejection conditions : Not accepted during indoor operation
Setting start operation method : Press the SET (S007) key for one second.
Setting change operation method : After entering the setting start operation mode, operating the UP
(S005) and DOWN (S006) keys makes it possible to change the setting
values. (TEST/WARNING LED light)
Example:

: When pressing the UP (S005) key

: When pressing the DOWN (S006) key
Setting confi rm operation method : After entering the setting start operation or setting change operation
completed, press the SET (S007) key for one second. (TEST/
WARNING LED off)
Setting cancel operation method : Press the HOME (S004) key for one second before confi rming setting.
Setting range : 00 to 02
0 3WAY MULTI

1• •
2• •
9) Model 2 setting (Level 2)
Rejection conditions : Cannot be accepted when the indoor unit is operating.
Operations to start settings : Press the SET (S007) key for one second.
Operations to amend settings : After performing the operations to start the settings, press the UP
(S005) and DOWN (S006) keys to change the set values. (The TEST/
WARNING LED will be illuminated.)
Example:

: When the UP (S005) key is pressed

: When the DOWN (S006) is pressed
Setting confi rm operation method : Press the SET (S007) key for one second after starting the settings
or after amending the settings. (The TEST/WARNING LED will be
extinguished.)
Setting cancel operation method : Press the HOME (S004) key for one second before entering the
settings.
Setting range : 00 to 07
0 Standard

1W MULTI

2 3WAY MILTI

3 (No current setting)

4 Standard Panasonic model

5 W-Multi Panasonic model

6 3WAY Panasonic model

7 (No current setting)

10) Region setting (Level 2)
Rejection conditions : Not accepted during indoor operation
Setting start operation method : Press the SET (S007) key for one second.
Setting change operation method : After entering the setting start operation mode, operating the UP
(S005) and DOWN (S006) keys makes it possible to change the setting
values. (TEST/WARNING LED light)
Example:

: When pressing the UP (S005) key

: When pressing the DOWN (S006) key
Setting confi rm operation method : After entering the setting start operation or setting change operation
completed, press the SET (S007) key for one second. (TEST/
WARNING LED off)
Setting cancel operation method : Press the HOME (S004) key for one second before confi rming setting.
Setting range : 00 to 02
0Europe

