Operation Manual
FT128 Rev 2.4
72
new fault can be shown, if there are more than 200). Corrected faults are shown in the
event log (menu H4/U6).
Notes:
• All faults have to be individually acknowledged one by one with push button
"Fault acknowledge" (P6). Use ↑ or ↓ keys to scroll.
• If a fault has been serviced / corrected before it has been acknowledged, the text
"Serviced" is added next to the time
52
. It still has to be acknowledged.
• When a fault is corrected and acknowledged, it will disappear from the list (H6).
• When all faults have been acknowledged, output(s) for routing equipment (Fault
tx) is (are) reset (i.e. the LED Routing equipment "Fault tx activated" will be
turned off).
• As long as there are faults (not acknowledged faults and/or acknowledged but
not corrected faults) the LED "General fault" (L7) will be lit and general fault (and
maybe general charge fault) output(s) are activated.
• Faults, corrected faults and acknowledged faults are shown in the General event
log (menu H4/U6).
52
Via EBLWin the faults can be set to be not latched. Corrected faults will in this case automatically disappear
from the list without being acknowledged before.
