Operation Manual
FT128 Rev 2.4
74
5. Turn “ON” the mains isolate switch (230 V
AC
)
53
Note: The Control Unit will be supplied pre-wired, the installer has to connect the
incoming mains to the GPO only.
6. Re-place the battery fuse (F2) on the main board.
7. LED "Operation" (L6) indicates that the 24 VDC supply (power supply and/or
battery) is okay.
8. An automatic restart will now take place, see chapter "Restart", page 82.
9. Once the basic operation of the panel is confirmed, power down the panel then
terminate the COM loop and field wiring into the expansion board (SUB835).
10. The site specific data (SSD) created in EBLWin can now to be downloaded, see
chapter "Software Download", Page 75.
See also chapter "Calibration of Supervised Outputs (H5/A1)", page 110.
Note: A “Safe shutdown” must be performed once FT128 is cleared of all faults and the
system becomes in normal operational mode.
53
The Control Unit is supplied with a GPO which has the mains isolate switch and a power point outlet used during
programming to connect the power cable to your PC.
