Panasonic FP0H

Specifications
12-6
12.2.3 When Using PWM Output Function
 Control unit
FP0H mode
Channel no. Output no. Control flag Output frequency (Duty)
CH0
Y0
R911C
1.0 Hz to 70 kHz: Resolution of 1000 (0.0% to 100.0%)
70001 Hz to 100 kHz: Resolution of 100 (0% to 100%)
CH1
Y3
R911D
CH2
Y8
R911E
CH3
YB
R911F
FPΣ mode
Channel no.
Output no.
Control flag
Output frequency (Duty)
CH0
Y0
R903A
1.0 Hz to 70 kHz: Resolution of 1000 (0.0% to 100.0%)
70001 Hz to 100 kHz: Resolution of 100 (0% to 100%)
CH2
Y3
R903C
 Maximum output frequency of pulse output/PWM output
These values are available only when the conditions of each item (such as output method or
channels) are executed. These values are available when the operations such as the high-
speed counter, pulse output function or other interrupt controls are not performed.
