Panasonic FP0H

FP Mode
11-6
11.2.2 High-speed Counter Instructions F165 (CAM0), F166 (HC1S), F167
(HC1R)
For the FPΣ mode, the following contents are common to FPΣ.
- Operations when instructions are executed
- Allocation of memory areas
 Operations when instructions are executed
In the FP0H mode, operations vary according to the system register no. 402 "Pulse/PWM
output settings".
Instruction
Conventional model
FP
Σ
series
FP0H series
FP
Σ
mode
FP0H mode
F165(CAM0) No instruction
No system register
setting
When the destination Y* when the
target value matches is other than the
normal output setting, an operation
error occurs.
F166(HC1S)
F167(HC1R)
No system register
setting
No system register
setting
When the destination Y* when the
target value matches is other than the
normal output setting, an operation
error occurs.
 Allocation of memory areas
Conventional model FPΣ series and FP0H series (FPΣ mode)
Channel no.
Input
Reset input
Elapsed value
Target value
Control flag
CH0 X0 X2
DT90044
DT90045
DT90046
DT90047
R903A
CH1 X1 X2
DT90048
DT90049
DT90050
DT90051
R903B
CH2 X3 X5
DT90200
DT90201
DT90202
DT90203
R903C
CH3 X4 X5
DT90204
DT90205
DT90206
DT90207
R903D
FP0H series (FP0H mode)
Channel no.
Input
Reset input
Elapsed value
Target value
Control flag
CH0 X0 X2
DT90300
DT90301
DT90302
DT90303
R9110
CH1 X1 X2
DT90304
DT90305
DT90306
DT90307
R9111
CH2 X3 X5
DT90308
DT90309
DT90310
DT90311
R9112
CH3 X4 X5
DT90312
DT90313
DT90314
DT90315
R9113
