Panasonic Lumix S1R User Manual

14. Menu Guide
330
[Focus/Shutter] ¨ ¨
[MF Assist]
[Focus Ring] `[ON]/[OFF]
[AF Mode/MF] [ON]/`[OFF]
[Press Joystick] [ON]/`[OFF]
[MF Assist Display] [FULL]/`[PIP]
This sets the display method of MF Assist (enlarged screen).
[Focus Ring]: The screen is enlarged by focusing with the
lens.
[AF Mode/MF]: The screen is enlarged by pressing [ ].
[Press Joystick]: Press the joystick to enlarge the display.
(if [Joystick Setting] is set to [D.FOCUS Movement]) (l 337)
[MF Assist Display]: Sets the display method (windowed
mode/full screen mode) of MF Assist (enlarged screen).
0 While you are using the following functions, MF Assist will
not be displayed:
– Video recording
– [6K/4K Pre-Burst]
[MF Guide]
`[ ]/[ ]/[OFF]
During MF, MF Guide, which acts as a guide to recording
distance, is displayed on the screen. You can select from
metres or feet for the display unit.
[Focus Ring Lock]
[ON]/`[OFF]
This disables the focus ring operation of the interchangeable
lens during MF to lock the focus.
0 [MFL] is displayed on the recording screen while the focus
ring is locked.
0 This menu item can be registered to the Fn button.
(l 278)

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
