Panasonic Lumix S1R User Manual

16. Connecting to Other Devices
428

Using VIERA Link (HDMI)
VIERA Link (HDMI) (HDAVI Control™) is a function that allows you to use
your remote control for the Panasonic TV for easy operations when the
camera has been connected to a VIERA Link compatible device using an
HDMI cable for automatic linked operations.
(Not all operations are possible.)
1
Connect the camera to a Panasonic TV compatible with VIERA Link
(HDMI) using a commercially available HDMI cable. (l 426)
2
Turn on the camera.
3
Turn on the VIERA Link.
0
¨ [ ] ¨ [ ] ¨ [TV Connection] ¨ [VIERA Link (CEC)] ¨ [ON]
4
Display the playback screen.
0
Press [(].
5
Operate with the remote control for the TV.
Power off link
If you turn off the TV with its remote control, the camera will also turn off.
Automatic input switching
If you turn on the camera and then press [(], the input of the TV automatically
switches to input to which this camera is connected.
Furthermore, when the TV power is in the standby state, it turns on automatically.
(When “Power on link” on the TV is set to “Set”)
0 To use VIERA Link (HDMI), you need to also configure the settings on the TV.
For the setting procedure, refer to the operating instructions for the TV.

Panasonic Lumix S1R Specifications

General

Sensor Resolution	47.3MP
Sensor Type	Full-frame CMOS
ISO Sensitivity	100-25600 (expandable to 50-51200)
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Camera Type	Mirrorless
Sensor Size	36 x 24 mm
Lens Mount	L-Mount
Shutter Speed	1/8000 to 60 sec, Bulb
Connectivity	Wi-Fi, Bluetooth
Battery	DMW-BLJ31 Lithium-Ion
Dimensions	148.9 x 110.0 x 96.7 mm
Autofocus System	Contrast Detection AF System with DFD Technology
Viewfinder	5.76 million dots OLED EVF
LCD Screen	3.2-inch, 2.1 million dots, touch screen
Video Recording	4K up to 60p
Continuous Shooting	9 fps (AFS/MF), 6 fps (AFC)
Weather Sealing	Yes
Memory Card Slots	2x SD Card Slots (1x UHS-II Compatible)
