Parker Hannifin S.p.A Divisione S.B.C. user’s manual TWIN-N and SPD-N
97
b180.1
Start Tab.1 on master phase of Pr170:171. =1 enables Tab0 at the master phase
declared in Pr171:170. The parameter values to start on master phase must be
between 0 and Pr111:110 master module.
b180.2
Start Tab.2 on master phase of Pr172:173. =1 enables Tab0 at the master phase
declared in Pr173:172. The parameter values to start on master phase must be
between 0 and Pr111:110 master module.
b180.3
Start Tab.3 on master phase of Pr174:175. =1 enables Tab0 at the master phase
declared in Pr175:174. The parameter values to start on master phase must be
between 0 and Pr111:110 master module.
b180.4
Immediate start Tab.0. =1, TAB0 immediate activation. Indication of which table
is active in CAM1 generator.
b180.5
Immediate start Tab.1. =1, TAB1 immediate activation. Indication of which table
is active in CAM1 generator.
b180.6
Immediate start Tab.2.
=1, TAB2 immediate activation. Indication of which table
is active in CAM1 generator.
b180.7
Immediate start Tab.3. =1, TAB3 immediate activation. Indication of which table
is active in CAM1 generator.
b180.8
(0)Upgrade automaticaly to CAM1-(1)Upgrade CAM1 only on engagé
(b180.10 or b180.13).
b180.9
CAM 1 engaging immediatly ( Signal lock/Unlock CAM 1).
b180.10
Electronic CAM2 engaging on master phase 0.
b180.11
Electronic CAM2 release on master phase 0.
b180.12
CAM 2 engaging immediatly ( Signal lock/Unlock CAM 2).
b180.13
Electronic CAM2 execution on single shot.
b180.14
(0)Cought quota master frequency imput (1) Cought quota Motor position-
Storage in Pr58:59.
b180.15
Enable swap table (engage/releaselinear).
b181.0
Enabled Tab.0 in the Cam. =1 TAB0 is enabled.
b181.1
Enabled Tab.1 in the Cam. =1 TAB1 is enabled.
b181.2
Enabled Tab.2 in the Cam. =1 TAB2 is enabled.
b181.3
Enabled Tab.3 in the Cam. =1 TAB3 is enabled.
b181.4
Command swap of Tab.0 (Tab.0-Tab1-Tab.3).
The switching between the tables
is showed in the picture.
The switching starts from TAB0 to TAB3, counterclockwise direction.
b181.5
Command swap of Tab.3 ( Tab.3-Tab2-Tab.0). The switching between the tables
is showed in the picture.
The switching starts from TAB3 to TAB0, clockwise direction.
b181.6
Selection Table in the CAM 2. The state of this bit, together with bit b181.7,
identifies the selected table (see table below*).
b181.7
Selection Table in the CAM 2. The state of this bit, together with bit b181.6,
identifies the selected table (see table below*).
* Table
selection
b181.6 b181.7
Tab0 1 1
Tab1 1 0
Tab2 0 1
Tab3 0 0
b181.8
Enable virtual table (Tab.3).
