Peri Trio - Page 32

28
20
23
240
240
90
60
240
240
60
60
90
26
27
28
27
20
240
240
120
120 240
240
80
80
TRIO Panel Formwork
Instructions for Assembly and Use – Standard Configuration
A7 Corners
Wall thickness 80 cm
Panel connection with h = 2.70 m:
– 3 x Alignment Coupler BFD (20) for
a length L of 3.0 m per panel joint
– Universal Waler 245 (26) with Waler
Stop (27) and Tie Yoke (28)
(Fig. A7.06 + A7.06a)
Right-angled corners
Wall thicknesses of 60 cm and 80 cm.
Perm. fresh concrete pressure 60 kN/m².
Wall thickness 60 cm
Panel connection with h = 2.70 m:
– 3 x Alignment Coupler BFD (20) for
a length L of 2.25 m per panel joint
– Compensation Waler TAR 85 (23)
(Fig. A7.05 + A7.05a)
Fig. A7.05
Fig. A7.06
TE
TRM 72
L
L
TE
L
L
Fig. A7.05a
Fig. A7.06a
AuV TRIO EX.indb 28 11.10.17 09:46
