TRIO Panel Formwork
Instructions for Assembly and Use – Standard Configuration
A9 T-junctions
Obtuse-angle wall
connection
With Panel TR 270 x 240.
(Fig. A9.03)
With Multi-Purpose Panel TRM 72.
(Fig. A9.04)
With Wall Thickness Compensator
WDA (18) or timbers.
(Fig. A9.05)
With Cam Nut DW 15 (19).
(Fig. A9.06)
Fig. A9.04
Fig. A9.03
Fig. A9.05
Fig. A9.06
270 x 240
TRM 72
270 x 240
TRM 72
