VR2 CONTROL SYSTEM
SK77898/2
PG DRIVES TECHNOLOGY
94
button once illuminates the LEFT LED, and deflection of the joystick forwards or
backwards will adjust the actuator connected to that channel. Selection between the
two actuators is achieved by deflecting the joystick to the left and right. As the actuator
selected changes then so will the LED, which illuminates. LEFT for actuator 1 and RIGHT
for actuator 2.
To re-enter drive mode, depress either the actuator button or the speed button
2.4 Maximum Speed Button and Indicator
2.4.1 Maximum Speed Indicator
This shows the maximum speed setting for the wheelchair when the dual attendant
system has control. There are five settings - setting 1 is the lowest speed and setting 5
is the highest speed. The speed setting is changed with the speed button.
2.4.2 Maximum Speed Button
This sets the maximum speed of the wheelchair when the dual attendant system has
control.
If the control system is programmed for drive profile operation, then the dual attendant
system speed adjuster button will only adjust the speed within the selected profile.
Changing between drive profiles can only be achieved using the VR2.
