PG Drives Technology VR2 series User Manual

VR2 CONTROL SYSTEM
SK77898/2
PG DRIVES TECHNOLOGY
96
VR2 DUAL ATTENDANT SYSTEM CONNECTION CONFIGURATION
DUAL
MODULE
ATTENDANT
MODULE
INTERMEDIATE
CABLE
To Power
Module
To Joystick
Module
4 Connection
Secure all cables to the wheelchair frame over as much of
their length as is practical.
4.1 Connetion to the VR2 Dual Attendant
The VR2 dual attendant system is connected to the VR2 Dual Attendant Control System
via a designated cable as shown below using the cable supplied.

PG Drives Technology VR2 series Specifications

General

Brand	PG Drives Technology
Model	VR2 series
Category	Control Systems
Language	English
