VR2 DUAL ATTENDANT SYSTEM CONNECTION CONFIGURATION
DUAL
MODULE
ATTENDANT
MODULE
INTERMEDIATE
CABLE
To Power
Module
LIGHTING
MODULE
1 2
VR2-L
Including a VR2 Dual Attendant Module into a lighting configuration.
