VR2 CONTROL SYSTEM
SK77898/2
PG DRIVES TECHNOLOGY
114
Trip
Code
Trip
Type
Description & Reference
1505
Left Solenoid Brake Trip (3.9)
9
1320
Refer to section (3.16)
-
1506
Right Solenoid Brake Trip (3.9)
9
1600
High Battery Voltage (3.10)
10
1E03
Refer to section (3.6)
6
1E04
Refer to section (3.13)
Charging
1E05
Refer to section (3.14)
Charging
2C00
Low Battery Voltage (3.1)
1
2C02
Low Battery Lockout (3.1)
-
2F00
Refer to sections (3.7 & 3.11)
User
3B00
Left Motor Disconnected (3.2)
2
3C00
Right Motor Disconnected (3.4)
4
3D00
Left Motor Wiring Trip (3.3)
3
3D01
Left Motor Wiring Trip (3.3)
3
3E00
Right Motor Wiring Trip (3.5)
5
3E01
Right Motor Wiring Trip (3.5)
5
5400
Communications Trip (3.12)
7 + S
4401
Control System Trip (3.8)
8
7A03
Actuator Motor Wiring Trip (3.15)
A Only
7100
Joystick Trip (3.7)
7
7101
Joystick Trip (3.7)
7
7102
Joystick Trip (3.7)
7
7103
Joystick Trip (3.7)
7
7104
Joystick Trip (3.7)
7
7147
Dual Joystivck Displaced Refer to section (3.11)
User
7902
Refer to section (3.17)
-
Possible Control System Trip (3.7 & 3.8)
All Other
Codes
7 or 8
1
2
3 Trip Types and Their Possible Causes
Once the trip type has been established, refer to the relevant section below for further
information.
1 - S = Flashing Speed Indicator LEDs.
2 - A = Flashing Actuator LEDs.
