1.3 Soft-Stop
The VR2 has a programmable value called Soft Stop Rate which sets the emergency
stopping distance. You must ensure that the emergency stopping distance is within
the distance specified for the country in which the wheelchair will be used. TÜV
Product Service (Germany) specify the distance to be as stated in EN12184.
1.4 Other Information
You must provide a diagram in the wheelchair user handbook showing the user
controls and the main features of the control system.
In addition, you should include a brief specification of operating supply voltage
range and operating temperature range.
1.5 Control System Make-up
The VR2 Control System is made-up of a minimum of 2 modules, the Joystick Module
and the Power Module. The following table shows the relationship between the two
modules.
Power Module
VR2 60
VR2 60 (A1)
60A Output, No Actuators
60A Output, 1 Actuator
VR2 60 (A2)
60A Output, 2 Actuators
Description
JSM
VR2 50
50A Output, No Actuators JSM
VR2 40
40A Output, No Actuators JSM
JSM-A
JSM-A
VR2 70
VR2 70 (A1)
70A Output, No Actuators
70A Output, 1 Actuator
VR2 70 (A2)
70A Output, 2 Actuators
JSM
JSM-A
JSM-A
Joystick Module
