16.0 IQ Back for Hasselblad H Series
The Phase One IQ (H-mount) digital back is designed specically for
Hasselblad H1 and H2 cameras.
16.1 Mounting the IQ back on the Hasselblad H1/H2
1. Ensure that the mirror is up and the shutter is open. (This is the default
position when no cassette is attached to camera body).
2. Place the bottom of the IQ back in the locking mechanism.
3. Lever the back into place.
4. Do not let go of the back until you hear a clicking noise that signals the
back is locked into position. The mirror will come down and shutter will close
when IQ back is attached to the camera.
N.B. It is important to ensure that the bottom part of the IQ back is attached
correctly before the upper locking mechanism is pressed together.
Removing the IQ back from the Hasselblad H1/H2
1. Rotate and press the silver button (illustrated left) to unlock the back.
(Ensure that the back is supported in your hand before pressing this button).
2. Gently lever away the top of the back rst. Be careful with the contacts
and protective glass on the back.
N.B. Your IQ back should always be protected by its plate when it is not
attached to the camera.
