24
2.13 The Buttons on the Back
The IQ is equipped with four external buttons. The buttons will change
function to match the menu shown on the sceen. Find out more on the IQ
menus from page 75.
2.14 LED Lights
IQ Series digital backs feature two main LEDs located below the bottom left
corner of the screen.
Green: When capturing an image the green LED will blink rapidly to indicate
that the IQ back is busy.
A continuous green light indicates that the backlight of the display is dimmed
but the camera is still ready to shoot. (The Display O Time can be set in the
IQ back’s Menu mode in the Power Management options).
Red: A red LED indicates that the IQ back is writing to the storage media, and
therefore the buer has not been emptied.
There is an additional red LED indicator located next to the CF card slot (under
the cover). It is assigned to indicate CF card activity only. Do not remove a CF
card from the card slot when this red LED is on. Removing a CF card whilst
the red LED is on can damage the formatting of the card, and images or data
might be lost or corrupted.
The IQ Series Home screen
Menu
Play
ISO
WB
