20
2.9 Attaching the IQ2 Back
The IQ back is fully integrated with the camera body and functions as a part
of the whole camera system.
Ensure that the Phase One 645DF+ camera mirror is up and the shutter is
open when no digital back is attached.
When attaching the IQ back to the camera body the shutter will close and
the mirror come down.
First remove the cover on the IQ back and 645DF+ camera. Next, slide forward
the lever [1] and push in button [2], and ensure that the bottom part of the
IQ back is placed correctly in the lower locking mechanism on the back of
the camera body before the upper locking mechanism is pressed together.
Failure to do this can cause an error with the camera body where the shutter will
continuously open and close. If this occurs, remove the IQ back. Make sure the
camera body is powered and press button while mounting the digital back.
Please be aware that the shutter should be in the correct starting position
(shutter open). If this is not the case, attach and remove the IQ back again to
make sure that the camera body gets in the correct starting position.
Remove the IQ back by sliding forward the lever [1], pushing in button [2],
and by gently pulling away the top of the back rst. Be careful with the
contacts and protective glass on the back. Your IQ back should always be
protected by its plate when it is not attached to the camera.
1
2
