Philips Respironics SimplyGo Mini User Manual

16
SimplyGo Mini User Manual
Charging the Battery
Important: The rst time you charge the battery, be sure to charge it fully� Do
not use the DC power cord to do so; instead use AC power�
Note: The battery will begin charging whenever you connect the device to an
AC outlet, regardless of whether or not you are operating the device�
To charge the battery using the AC Power Cord provided with your system,
follow these steps�
1� Connect the AC Power Supply’s output cable to the SimplyGo Mini
power input connector�
2� Connect the AC Power Cord’s connector into the AC power supply�
3� Connect the AC Power Cord’s plug into an AC outlet installed to meet
national or regional electrical code�
1
2
Note: The AC Power Supply is equipped with a green light, which illuminates
as soon as you connect the device to an energized AC power source�
4� When charging is complete (this takes four hours or less for the
standard battery), disconnect the AC Power Supply and store it with
the AC Power Cord for future use�
Note: Replacement and spare batteries are available separately� For
information, contact your equipment provider�
Note: An optional SimplyGo Mini Smart Battery Charger (sold separately)
is available for your system� For more information, contact your
equipment provider�

Philips Respironics SimplyGo Mini Specifications

General

Battery Duration (Standard Battery)	Up to 4.5 hours
Battery Life	Up to 4.5 hours with standard battery, up to 9 hours with extended battery
Oxygen Concentration	87% to 96% at all settings
Pulse Dose Settings	1 to 5
Recharge Time (Standard Battery)	Approximately 4 hours
Recharge Time (Extended Battery)	8 hours
Operating Altitude	Up to 10, 000 feet (3048 meters)
Sound Level	43 dBA (at pulse dose setting 2)
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Altitude Range	Up to 10, 000 feet (3048 meters)
Weight	5 lbs (2.3 kg) with standard battery
Humidity Range	15% to 95% non-condensing
