All means all ports will have one specific setting.
Contro
ls the default PCP
value. All frames are classified to a PCP value.
If the port is VLAN aware and the frame is tagged, then the frame is classified to
the PCP value in the tag. Otherwise the frame is classified to the default PCP
value.
All means all ports will have one specific setting.
 PCP
Contro
ls the default DEI
value. All frames are classified to a DEI value.
If the port is VLAN aware and the frame is tagged, then the frame is classified to
the DEI value in the tag. Otherwise the frame is classified to the default DEI
value.
All means all ports will have one specific setting.
 DEI
Sho
ws the classification mode for tagged frames on this port.
 Disabled: Use default CoS and DPL for tagged frames.
 Enabled: Use mapped versions of PCP and DEI for tagged frames.
Click on the mode in order to configure the mode and/or mapping.
Note: This setting has no effect if the port is VLAN unaware. Tagged frames
received on VLAN unaware ports are always classified to the default CoS and
DPL.
 T
ag Class.
Click to Ena
ble DSCP Based QoS Ingress Port Classification.
 DSCP Based
T
he IP/MAC address mode specifying whether the QCL
classification must be
based on source (SMAC/SIP) or destination (DMAC/DIP) addresses on this port.
The allowed values are:
 Source: Enable SMAC/SIP matching.
 Destination: Enable DMAC/DIP matching.
 A
ddress Mode
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
