User’s Manual of IGS-604HPT-M12
202
4.9.13 Storm Control Configuration
Storm control for the switch is configured on this page. There is a unicast storm rate control, multicast storm rate control, and a
broadcast storm rate control. These only affect flooded frames, i.e. frames with a (VLAN ID, DMAC) pair not present on the MAC
Address table.
The configuration indicates the permitted packet rate for unicast, multicast or broadcast traffic across the switch.
The Storm Control Configuration screen in Figure 4-9-15 appears.
Figure 4-9-15: Storm Control Configuration Screenshot
The page includes the following fields:
Object Description
T
he port number for which the configuration below applies.
 Port
T
he settings in a particular row apply to the frame type listed here:
 unicast
 multicast
 Broadcast
 F
rame Type
Enab
le or disable the storm control status for the given frame type.
 Enable
T
he rate unit is packets per second (pps). Valid values are: 1, 2, 4, 8, 16, 32, 64,
128, 256, 512, 1K, 2K, 4K, 8K, 16K, 32K, 64K, 128K, 256K, 512K , 1024K,
2048K, 4096K, 8192K, 16384K or 32768K.
 Rate
